EDOO M1-R Miniature industrial barcode scanner module engine for industrial tablets

Product Feature

• Independent Core Technology

       Adopts self-developed core decoding technologyand dual -CPU architecture, delivering excellentdecoding performance for 1D and 2D barcodes

• Multiple Interface

   Provide USB and TTL232 interfaces to meet more application needs。

• Industrial reading performance

    Using red backlighting and industrial algorithms, it’s possible to read DPM QR codes engraved on surfaces of various industrial materials such as metal, PCBs, and plastic. It can also process damaged, incomplete, or distorted barcodes.Support for outdoor bright light is adaptability.

• Compact size

        Size(mm)：21mm*9mm*7.1mm

• Complete range of coding systems

    Supports all major 1D and 2D barcodes worldwide，Supports passport OCR scanning

    Application scenarios  Express cabinets, ticket machines, display booths, various self-service application devices, etc。
